Siglent SVA1000X – Spectrum & Vector Analyzer
- Vector Network Analysis: Now included as standard, covering frequencies from 100 kHz to 3.2 / 7.5 GHz
- Distance-to-fault: Optional feature
- Spectrum Analyzer mode: Frequency range extends from 9 kHz to 1.5 / 3.2 / 7.5 GHz
- Displayed Average Noise Level (Typ.): -156 dBm/Hz / -161 dBm/Hz / -165 dBm/Hz
- Offset Phase Noise (Typ.): -99 dBc/Hz @10 kHz Offset (1 GHz)
- Minimum Resolution Bandwidth (RBW): 1 Hz
SEND US A MESSAGE
CONTACT INFORMATION
Do you have questions about how we can help your company? Send us an email and we’ll get in touch shortly.
The SIGLENT SVA1000X Spectrum and Vector Network Analyzers serve as versatile and robust tools for RF signal and network analysis. Covering frequencies up to 7.5 GHz, the SVA1000X analyzer offers dependable automatic measurements and various operational modes. Its base model functions as both a spectrum analyzer and a vector network analyzer, with optional features including a distance-to-fault locator and a vector signal modulation analyzer.
Applications for the SVA1000X Spectrum and Vector Network Analyzers encompass broadcast monitoring/evaluation, site surveying, S-parameter measurement, cable and antenna testing, analog/digital modulation analysis, EMI pre-compliance testing, research and development, education, production, and maintenance.
| Manufacturers | |
|---|---|
| Models | SVA1015X ,SVA1032X ,SVA1075X |
