The GS820 expands upon the conventional source measure unit technology by featuring two channels of four quadrant operation. Each channel is isolated from one another and comes armed with a voltmeter, ammeter, voltage source and current source.
Yokogawa GS820 – Multi Channel Source Measure Unit
- Isolated 2-channel source and measurement function
- Source and measurement ranges
18 V model: 7 V and 3.2 A or 18 V and 1.2 A
50 V model: 20 V and 1.2 A or 50 V and 0.6 A - 1pA resolution at extremely small current range 200 nA
- Generate arbitrary waveforms consisting of up to
100000 points at 100 µs intervals - Channel expansion through master-slave
synchronization link - Fast test speeds
